| Summary | Modern, edgeless linear look with front/corner/bay installs and app control—great when you want a slim,
contemporary centerpiece with Comfort$aver heat. | Choose this if you want plug-in convenience plus Comfort$aver® efficiency, adjustable flame speed, and an
included glass pane—the “fully loaded” Revillusion. | Best for a traditional built-in firebox with the Revillusion flame, Realogs®, and a full-depth, see-through
brick interior—authentic fireplace vibes with strong heat. | Go BF if you want classic fireplace charm and straightforward operation—traditional brick interior, Dimplex
flame effect, and heat up to 1,000 sq. ft. | Go BF if you want classic fireplace charm and straightforward operation—traditional brick interior, Dimplex
flame effect, and heat up to 1,000 sq. ft. | Easiest choice for simple retrofit/plug-in use—quick comfort, adjustable flame speed/brightness, and options
for logs or crystals. | Value-forward built-in with molded logs, 3 speeds, 3 brightness, 13 flame colors, and flexible hard-wire or
plug-in install. | Water-vapor **Optimyst®** firebox with realistic logs, onboard/remote control, **Flame Connect App**, and
**fan-forced heat** for up to **400 sq. ft.** | Compact **Optimyst®** hearth insert with realistic logs, pull-out refill drawer, onboard/remote control, and
**fan-forced heat** up to **400 sq. ft.** | Water-vapor **Optimyst®** cassette (20") for custom build-ins or Pro Box. Flame-only module (no
heater). Plumbable or tank-fed; remote control. |
|---|
| Size | 30", 36", 42", 48" | 24" | 30", 36", 36"P, 42" | 33" | 33", 39", 45" | 23", 26", 28", 33" | 26", 28", 33", 36", 42" | 30" | 25" | 20" module |
|---|
| Ember Bed | Quick Connect Logs with Tumbled Glass Embers | Realogs® | Realogs® | Inner Glow Logs | Inner Glow Logs | Acrylic Crystals, Realogs® | Molded Logs | Realistic Charred Logs | Realistic Charred Logs | Open water-vapor “burner” (use with compatible logs/media) |
|---|
| Ember Bed Color Settings | 3 Themes | Adjustable Brightness | • | • | • | • | • | 5 Colors | 3 Brightness | 6 Themes | Adjustable Brightness | 6 Themes | Adjustable Brightness | — |
|---|
| Interior Surround | Black | Herringbone or Weathered Concrete Interior | Black | Black | Black, Authentic brick-look interior | Black | — | — | — | — |
|---|
| Flame Effect | Dynamic-Fire | Revillusion® Flame | Revillusion® Flame | Original Dimplex® Flame | Original Dimplex® Flame | Original Dimplex® Flame | — | Optimyst® Flame effect | Optimyst® Flame effect | Optimyst® Flame effect |
|---|
| Flame Technology | Optiflame® | Optiflame® | Optiflame® | Optiflame® | Optiflame® | Optiflame® | — | Optimyst® | Optimyst® | Optimyst® |
|---|
| Flame Speed | 4 | • | • | | | | 3 | — | — | — |
|---|
| Flame Only Mode | • | • | • | • | • | • | • | • | • | • |
|---|
| Light Settings | Top Light | Mood Lighting, Brightness and Flicker, Ambient Light Sensor | | | | Adjustable Brightness | Adjustable Brightness | Top Light | Top Light | Top light (module) |
|---|
| Heat Operation | Comfort$aver® Heating | Comfort$aver® Heating | Powerful Supplemental Heat | Option to use 240V supply for up to 9200 BTU | | Supplemental Heat | Fan-forced supplemental heat | Powerful heating | Powerful heating | — (no heater) |
|---|
| Heating Range | Up to 1000 sq. ft. | Up to 1,000 sq. ft. | Up to 1,000 sq. ft. | Up to 1,000 sq. ft. | Up to 1,000 sq. ft. | Up to 1,000 sq. ft. | Up to 1,000 sq. ft. | Up to 400 sq. ft. | Up to 400 sq. ft. | — |
|---|
| Heater Only Mode | • | • | • | When connected to a switch or thermostat | | • | | — | — | — |
|---|
| Heater Element | Ceramic | Ceramic | Steel Sheathed | Steel Sheathed | Steel Sheathed | Stitched Wire | — | — | — | — |
|---|
| Heat Disable | Onboard controls or hardwire disconnect | | Hardwire disconnect only | | | Onboard controls | — | • | • | — |
|---|
| Built-in Thermostat | • | • | • | | • | | | • | • | — |
|---|
| Connects to a Wall Thermostat | • | • | | | | | | | | — |
|---|
| Wiring Type | Hardwire (Optional 120V Plug Kit Included) | Hardwire (Optional 120V Plug Kit Included) | Hardwire (Optional 120V Plug Kit Included) | | | Plug-in | Hard-wire or Plug-in | Hardwire (120V Plug Kit Included) | Hardwire (120V Plug Kit Included) | Hardwire or Plug-in* |
|---|
| Volts | 120 | 240 | 120 | 120 / 208 / 240 | 120 / 208 / 240 | 120 / 208 / 240 | 120 | 120 | 120 | 120 | 120 |
|---|
| Watts | 1500 | 2500 | 1500 | 1375 / 1975 / 2575 | 1223 / 1823 / 2423 | 1440 / 2100 / 2700 | 1465 | 1500 | 1275 | 1250 | — |
|---|
| BTU | 5118 | 8530 | 5118 | 4400 / 6745 / 8794 | 4173 / 6220 / 8267 | 4913 / 7165 / 9213 | 5000 | — | 4350 | 4265 | 0 (flame-only) |
|---|
| Display | • | • | • | | | | | • | • | — |
|---|
| Onboard Controls | Onboard | Remote | App | Hidden-Touch Controls | Hidden-Touch Controls | Toggle | Toggle | Hidden-Touch Controls | Hidden control panel | Remote | App | Onboard controls | Remote | Onboard controls | Remote | Hidden control panel | Remote |
|---|
| Flame Connect App | • | | | | | | | • | • | — |
|---|
| Smart Self-diagnostics | • | | | | | | | • | • | — |
|---|
| Timer | • | • | • | • | | | | • | • | — |
|---|
| Optional Accessories | • | • | 30" only | • | • | XHD26/28G only | — | Plumb Kit, Plug Kit, Ember Beds & Log Sets | Plumb Kit, Plug Kit, Ember Beds & Log Sets | Plumb Kit, joining trays, log/media kits |
|---|
| Remote Control | • | • | • | • | | • | • | • | • | • |
|---|
| Warranty | 5-year parts and service | 2-year limited | 2-year limited | 2-year limited | 2-year limited | 2-year limited | 1-year limited | 2-year parts and service | 2-year parts and service | 2-year parts and service |
|---|
