In Stock
Dimplex Revillusion 36-inch Portrait Built-in Firebox with Glass Pane and Plug Kit (RBF36P-FG)
Free Shipping
$2,559.99
$2,844.43
- Stock: In Stock
- Model: 500002398
- MPN: 500002398
Revillusion is a completely new way of looking at fireplaces, and changing the standard for electric. A clear view through the lifelike flames, to the full brick interior, captures the charm of a wood-burning fireplace.
- Revillusion® Flame Technology - Revillusion Flame Technology produces ultrarealistic flames that mimic natural fire with the ability to dim the flames.
- Reflective Flame Panel - Includes a translucent acrylic panel that reflects the flames to make them appear from within the logs.
- ThruView™ Full-Depth Design - Enjoy a full view of the fireplace interior with the ability to see clearly through the flames —no obtrusion.
- Powerful Heating - Powerful fan-forced heater provides on-demand heat up to 1,000 square feet.
- Color Enhancement - Flame base colors include red and orange.
- Realogs® Plus - Features Realogs handcrafted and molded from real wood logs, which contain an inner lit LED light that add a glowing, pulsating effect as if the logs are burning.
- Brightness and Flicker - Adjust brightness of interior lighting from high to low to suit the room, including midnight mode which turns off lighting to reduce TV glare.
- All-Season Flames - Enjoy the unique charm of a fireplace 365 days a year without the heat.
- Just Plug It In / Direct-Wire - Unit comes with a 120V plug-in cord kit (not connected to the unit), allowing you to either plug it directly into a wall outlet or hardwire it to a 120V/240V power supply.
- Easy Installation - No venting, gas lines, or piping required; simply frame, wire and finish for quick and easy installation.
| Product Details | |
| BTUs | 4,400 | 6,745 | 8,794 |
| Dimensions | 37 1/4" W x 31 1/8" H x 12 1/8" D |
| Display/Controls | Capacitive touch built-in controls |
| Flame Only | Yes |
| Framing Dimensions | 36 5/8" W x 30 5/8" H x 12 1/2" D |
| Heat Operation | Primary-Heat - Option to use 240V supply for up to 8794 BTU |
| Heater Only | Yes |
| Heating Range | Up to 500 sq. ft. |
| Installation | Built-in |
| Interior Surround | Full-brick surround |
| Media | Realogs Plus |
| Portrait Version | The portrait version of the Dimplex Revillusion is taller than the original Dimplex Revillusion. |
| Remote Features | Mood-maker Remote |
| Technology | Revillusion Flame |
| UL Certification | 69098001000 |
| Voltage | 120 V | 208 V | 240 V |
| Warranty | 2 Years |
| Wattage | 1,375 W | 1,975 W | 2,575 W |
| Wiring | Direct-wire (120,208 or 240 volt circuit ) |
- Firebox
- Logs
- Tempered Front Glass
- RBF Plug Kit
- Mood Maker Remote
- Owner's Guide
